How to Install And Maintain Marine Gabion？

        Marine engineering gabion mesh is a flexible protective structure formed by filling metal woven mesh boxes with stones. Due to its water permeability, flexibility, dust permeability, and good environmental compatibility, it is widely used in coastal slope protection, dock protection, wave dissipation zones, and nearshore revetment projects.

        Ⅰ. Why choose woven gabion mesh

        1. Excellent erosion resistance and permeability, reducing backfill pressure and drainage work;

        2. Flexible construction and segmented installation, adaptable to settlement and terrain changes, resulting in low maintenance costs;

        3. Can be made of seawater corrosion-resistant materials such as galvanized steel, zinc-aluminum steel, or stainless steel, extending the project's lifespan.

        Ⅱ. How to Install Marine Gabion?

        1. Design and Site Preparation: Determine the gabion specifications, thickness, and anchoring method based on hydrological, wave, and geological surveys; clean and level the placement surface, and reinforce the foundation if necessary.

        2. Assembling the Gabion: Unfold the gabion panels according to the design dimensions and secure the partitions and side panels with binding wire or spiral connectors, ensuring each cell is secure and aligned.

        3. Layered Stone Filling: Select stones with the required particle size and strength, fill them evenly in layers, and compact them with vibration to avoid large     gaps and misalignment. Re-correct the shape before capping.

        4. Laying and Anchoring: For slopes or subsoil, use a mattress or stacking method, and enhance stability with ground anchors, anchor cables, or backfill as needed.

        Ⅲ. Gabion Mesh Maintenance & Inspection Guide

        • Regular inspections: It is recommended to inspect wire mesh joints, mesh damage, and stone loss seasonally or after major storm surges. Early repairs can prevent the spread of localized failures.

        • Local repairs: If damage to the gabion is found, the stones in the damaged unit should be unloaded first, the mesh replaced or reinforced, and then refilled. The washed-out foundation must be reinforced before further construction.

        Conclusion

        Marine engineering gabion mesh, with its flexibility, economy, and ecological compatibility, is suitable for a variety of scenarios, from shoreline protection to localized structural reinforcement. Fande can provide customized specifications, material recommendations, and construction technical support based on site surveys, ensuring that projects achieve both protective effects and optimized life-cycle costs.
